Curved Modular Belt Conveyor

C8M

Application

For transport tasks of all kinds

  • Accumulating operation
  • Incline conveyor tasks
  • Transport of heavy loads
  • Transport of cut parts
Product features
share-icon
Curved Modular Belt Conveyor - front end timing belt drive
Curved Modular Belt Conveyor Drive Options
Modular Belt Conveyor - nose bar deflection
Modular Belt Conveyor - curved incline conveyor
Modular Belt Conveyor - Incline conveyor with horizontal infeed and discharge section

Information

Belt design

  • Sideguards
  • Griptop
  • Cleats
  • Traverse cleats

Design options side view

  • Horizontal conveyor
  • Inclined conveyor with horizontal infeed section
  • Inclined conveyor with horizontal discharge section
  • Incline conveyor with horizontal infeed and discharge section

Design options top view

  • L shape
  • U shape
  • US Shape
  • S shape

Drive options

  • Front end direct drive
  • Front end timing belt drive

Modular belt design

  • Modular belt open

Technical data

Belt speeds

Drive Option

6m/min up to 30m/min

Conveyed material total load

on request

Drive power 230/400V

0.25kW to 0.55kW

Modular belt pitch

1 inch
